6061-T6 Indonesia Aluminum Formwork H Beam Panel Profiles

Description

We have adopted a more advanced system. The strength and rigidity of aluminum alloy formwork system are improved by optimizing the section of aluminum alloy formwork and surface powder coated treatment.

So, you will be able to purchase higher quality products at a lower price.

Aluminum alloy formwork system

Panel system:

It is made of extruded aluminum alloy profiles (6061-T6, etc.), which is light, high-strength, and good in integrity, so as to ensure convenient installation and repeated turnover of horizontal plates.

Supporting system:

Single support: adopt advanced early dismantling technology support system to ensure that the construction period of each layer structure is controlled within the range of 4 ~ 5 days. Through test verification, the vertical allowable bearing capacity reaches 20 ~ 25KPA.

Fastening system:

In the range of conventional height (2.8 ~ 3.2M), the rear flute system adopts the design principle of locally reinforcing 4 parts of the inner wall, 5 parts of the outer wall, openings and floating platforms, etc., to ensure the overall strength, stiffness and stability of the formwork system.

Two-way support:

The three-dimensional adjustment function can not only ensure the perpendicularity and flatness of the vertical components (walls and columns), but also enhance the horizontal stiffness and bearing capacity of the vertical components (walls and columns) to resist the transverse concrete pressure caused by pouring.

Accessory system:

Pins, pins, bolts and other hardware accessories are all made of high-quality products, and the performance and processing accuracy meet the relevant specifications and customer requirements.

Construction advantages

1. Good system integrity

The overall casting is sub-molded, and the structure is safer.

2. High construction efficiency and short construction period

Only one set of template is needed for the early mold removal system.

3. Good construction quality

High quality of concrete molding: verticality, flatness, horizontality, and high precision of section size.
The concrete surface has a good look and feel: it achieves the effect of fair-faced concrete without plastering.

4. Reduce the use of vertical transport machinery

Except for the first formwork going upstairs and the last time going downstairs, lifting equipment is used, all subsequent manual transfers are used.

5. Solve the shortage of skilled workers on the construction site

Simple installation, after a simple training, ordinary workers can be installed aluminum template.

6. Safe and civilized construction

The support system is simple and convenient, with large working space on site, personnel movement, smooth material handling, and clean and safe construction surface.

There is no construction waste, no need to store and clean up, and the construction site is easy to manage.

Economic benefit

The biggest cost advantage of the aluminum alloy template system is that it can be reused multiple times. At present, the standard template is used more than 300 times, and the damaged template can be recycled and re-casted.

At the same time, due to the high molding quality of the aluminum template, it can achieve the effect of plaster-free turbulence, saving a lot of cement, sand, water and mortar production, transportation and plastering labor costs, and its economic benefits as the number of repeated use increases The manifestation becomes more obvious.

Care for life, pay attention to safety.

Realize safe and civilized low-carbon construction, reduce site safety accidents.

Increase efficiency and reduce energy consumption.

The use of aluminum alloy formwork has high construction efficiency and reduces the energy consumption in building construction.

Reduce wood consumption and protect forest resources.

The aluminum alloy formwork can be used repeatedly for many times. After being damaged, it can be returned to the furnace and remelted. All of them are reused, which greatly reduces the waste of wood.

Save the use of river sand and protect water and land resources.

Due to the high forming quality of the aluminum alloy template, the effect of avoiding plastering can be achieved, and a large amount of cement, sand, water and mortar production, transportation and plastering labor costs are saved.

Product Parameters

      China Langfang Gome Aluminum Co., Ltd. was established in 1999 and has more than 20 years of aluminum and die-cast aluminum manufacturing experience. The company has 8 senior technicians, 24 intermediate technicians, and 700 operating workers. Our company adopts advanced ERP management system and advanced physical and chemical testing equipment to ensure quality. Now Gome Aluminum has passed the ISO9001 quality management system certification. The company insists on building a corporate brand with integrity, and promoting corporate development with innovation as the driving force. China Langfang Gome Aluminum has sophisticated production equipment, strong technical force, advanced production management system and perfect after-sales service system. We welcome you to discuss cooperation!
